Create the sample application of Frame-by-Frame Animation using a sequence of three images.

---

Code:

AndroidManifest.xml

<?xml version="1.0" encoding="utf-8"?>

<manifest xmlns:android="http://schemas.android.com/apk/res/android"

    package="com.jayesh.framebyframe">

    <application

        android:allowBackup="true"

        android:icon="@mipmap/ic_launcher"

        android:label="@string/app_name"

        android:roundIcon="@mipmap/ic_launcher_round"

        android:supportsRtl="true"

        android:theme="@style/AppTheme">

        <activity android:name=".MainActivity">

            <intent-filter>

                <action android:name="android.intent.action.MAIN" />

                <category android:name="android.intent.category.LAUNCHER" />

            </intent-filter>

        </activity>

    </application>

</manifest>

Activity_main.xml

<?xml version="1.0" encoding="utf-8"?>

<RelativeLayout

    xmlns:android="http://schemas.android.com/apk/res/android"

    xmlns:app="http://schemas.android.com/apk/res-auto"

    xmlns:tools="http://schemas.android.com/tools"

    android:layout_width="match_parent"

    android:layout_height="match_parent"

    tools:context="com.jayesh.framebyframe.MainActivity">

    <ImageView

        android:id="@+id/iv"

        android:layout_width="250dp"

        android:layout_height="80dp"

        android:layout_centerInParent="true" />

    <Button

        android:id="@+id/btn_start"

        android:layout_width="wrap_content"

        android:layout_height="wrap_content"

        android:text="START"

        android:layout_alignBottom="@+id/btn_stop"

        android:layout_marginStart="62dp" />

    <Button

        android:id="@+id/btn_stop"

        android:layout_width="wrap_content"

        android:layout_height="wrap_content"

        android:text="STOP"

        android:layout_alignParentBottom="true"

        android:layout_alignParentEnd="true"

        android:layout_marginEnd="52dp"

        android:layout_marginBottom="44dp" />

</RelativeLayout>

battery_anim.xml

<?xml version="1.0" encoding="utf-8"?>

<animation-list xmlns:android="http://schemas.android.com/apk/res/android">

    <item

        android:drawable="@drawable/a"

        android:duration="100"/>

    <item

        android:drawable="@drawable/b"

        android:duration="100"/>

    <item

        android:drawable="@drawable/c"

        android:duration="100"/>

    <item

        android:drawable="@drawable/d"

        android:duration="100"/>

    <item

        android:drawable="@drawable/e"

        android:duration="100"/>

    <item

        android:drawable="@drawable/f"

        android:duration="100"/>

    <item

        android:drawable="@drawable/g"

        android:duration="100"/>

    <item

        android:drawable="@drawable/h"

        android:duration="100"/>

</animation-list>

MainActivity.java

package com.jayesh.framebyframe;

import android.graphics.drawable.AnimationDrawable;

import android.graphics.drawable.BitmapDrawable;

import android.support.v7.app.AppCompatActivity;

import android.os.Bundle;

import android.view.View;

import android.widget.Button;

import android.widget.ImageView;

public class MainActivity extends AppCompatActivity {

    private Button btn_start,btn_stop;

    private ImageView iv;

    AnimationDrawable Animation;

    int duration = 100;

    @Override

    protected void onCreate(Bundle savedInstanceState) {

        super.onCreate(savedInstanceState);

        setContentView(R.layout.activity_main);

        iv = (ImageView)findViewById(R.id.iv);

        btn_start = (Button)findViewById(R.id.btn_start);

        btn_stop = (Button)findViewById(R.id.btn_stop);

        /* PART A : USING XML FILE */

//        iv.setBackgroundResource(R.drawable.battery_anim);

//        Animation = (AnimationDrawable)iv.getBackground();

        /* PART B : USING JAVA CODE*/

        BitmapDrawable frame1 = (BitmapDrawable)getResources().getDrawable(R.drawable.a);

        BitmapDrawable frame2 = (BitmapDrawable)getResources().getDrawable(R.drawable.b);

        BitmapDrawable frame3 = (BitmapDrawable)getResources().getDrawable(R.drawable.c);

        BitmapDrawable frame4 = (BitmapDrawable)getResources().getDrawable(R.drawable.d);

        BitmapDrawable frame5 = (BitmapDrawable)getResources().getDrawable(R.drawable.e);

        BitmapDrawable frame6 = (BitmapDrawable)getResources().getDrawable(R.drawable.f);

        BitmapDrawable frame7 = (BitmapDrawable)getResources().getDrawable(R.drawable.g);

        Animation = new AnimationDrawable();

        Animation.addFrame(frame1,duration);

        Animation.addFrame(frame2,duration);

        Animation.addFrame(frame3,duration);

        Animation.addFrame(frame4,duration);

        Animation.addFrame(frame5,duration);

        Animation.addFrame(frame6,duration);

        Animation.addFrame(frame7,duration);

        Animation.setOneShot(false);

        iv.setBackgroundDrawable(Animation);

        btn_start.setOnClickListener(new View.OnClickListener() {

            @Override

            public void onClick(View v) {

                iv.post(new Runnable() {

                    @Override

                    public void run() {

                        Animation.start();

                    }

                });

            }

        });

        btn_stop.setOnClickListener(new View.OnClickListener() {

            @Override

            public void onClick(View v) {

                Animation.stop();

                System.exit(0);

            }

        });

    }

}

OUTPUT:
